Adapter #90 20amp 14-xx Plug to 5-15 / 5-20 socket adapter 3.5ft. For 2016+ Volt and Bolt EVSE's Also for Chrysler Pacifica Plug-in Hybrid
Sometimes you just need something custom! This adapter is amazing! It has a 14-xx universal plug and a 5-15 / 5-20 outlet. With this adapter you can connect a 240v compatible device that's equipped with a 120v 5-15 or 5-20 plug to a any of three outlets, it will fit into the 14-50 outlets commonly found in RV parks as well as a 14-30 outlet which is the newer dryer outlet allowing you to take it on the road and plug into a friends newer dryer outlet. The EVSE and our electric vehicles don’t require the neutral line so this plug works slick by eliminating the neutral blade, we can then plug into several 14-series NEMA outlet.
Also allows you to plug your EVSE into:
NEMA 14-30 (common dryer outlet)
NEMA 14-50 (common Range/Stove outlet)
NEMA 14-60 (found at some Fair grounds)
Be sure to check the information plate on your device or check online to insure it can handle 240 volts, some factory EVSE are 240v compatible and are not labeled such as the EVSE's that come with the Chrysler Pacifica Plug-in Hybrid and the stock EVSE's included with the 2016-2018 GM Volt and GM Bolt
Example uses are:
Boost the output of the stock EVSE included with the new Chrysler Pacifica Plugin Hybrid Electric Vehicles (PHEV) to cut charge times in half.
Boost the output of the stock EVSE included with the 2016-2018 GM Volt and GM Bolt to cut charge times in half. Look for GM part #2427-7224 or #2428-0118 or #2428-8872 (these are just a few of the known numbers)
